WIFI products are a common type of product on the market. Japan’s radio law has strict mandatory requirements for such products, and related products must apply for TELEC certification. This certification is similar to the domestic SRRC certification, which requires type approval by Japan Radio Law (mainly for the RF part). For different products, frequency bands and modulation methods, the test items and test methods required by TELEC are different.

TELEC certification introduction

The "Radio Law" requires the type approval of designated radio equipment (that is, the certification of compliance with technical regulations). TELEC certification is mandatory, and the certification body is a registered certification body recognized by MIC in the scope of designated radio equipment. TELEC (Telecom Engineering Center) is the main registered certification body for conformity certification of radio equipment in Japan. Wireless products exported to Japan (Bluetooth products, mobile phones, WIFI routers, drones, etc.) need to be certified by TELEC. TELEC is also called MIC certification in Japan. TELEC is one of the designated certification bodies of MIC, so it is collectively called TELEC certification.

Main test items of WIFI products

1. Frequency Error Measurement (Frequency Error Measurement);

2. Coupling bandwidth/carrier frequency bandwidth test (Occupied Bandwidth and Spread-spectrumBandwidth / Factor);

3. Unwanted Emission Intensity Measurement;

4. Antenna Power Error Measurement (Antenna Power Error Measurement);

5. Receiver spurious disturbance test (Limitation of Collateral Emission of Receiver Measurement);

6. EIRP antenna power test (Transmission Antenna Gain (EIRP Antenna Power) Measurement);

7. 3dB lobe bandwidth test (Transmission Radiation Angle Width (3dB Beamwidth) Measurement);

8. Interference protection and carrier sensing (Radio Interference Prevention Capability & Carrier Sense Capability Measurement).

Information to be submitted for TELEC certification of WIFI products

1. Technical Type Specification Form (Technical Type Specification Form);

2. Declaration of Quality Management System (Declaration of Quality Management System);

3. Control and approval method of quality certificate or ISO9001 certificate (Letter of Quality Control Confirmation Methodor Manufacturer's ISO 9001 Certificate);

4. Letter of Construction Protection Confirmation (Letter of Construction Protection Confirmation);

5. Rated Power Declaration;

6. Antenna Report (Antenna Report);

7. Test Reports (including Test Results, Test Setup Photos and Examinations carried out);

8. Label Information (Label Location, Label content);

9. Power of Attorney / Authorization Letter.

For TELEC certification of WIFI products, please contact our company ZRLK. We will provide you with professional and efficient testing and certification services, with favorable prices and courteous service. If you have other wireless products that require TELEC certification, please provide us with product pictures and specifications. We will provide the corresponding cycle, quotation and specific plan according to your product. Welcome to inquire!
