What is SRRC certification?

The Chinese Model Approval is abbreviated as SRRC certification, which is a national compulsory certification designed to distinguish between the civilian band and the military band in the wireless band. It is the technical management of the spectrum parameters and technical indicators of the radio transmission equipment before it is put into use in the development, production, import, and purchase links. Since June 1, 1999, radio component products sold and used in China must obtain radio model approval. Domestically produced, sold and used radio transmission equipment must be type approved, and the approval certificate and type approval code must be issued. The type approval code must be indicated on the label of the factory equipment.

Information required for Bluetooth module to apply for SRRC

1. Application form (two copies);

2. Power of attorney (two copies);

3. The customer's business license (Business license);

4. The number of prototypes depends on different products, of which three to five are required to lead out the RF cable (ie, radio frequency port or SMA port);

5. The customer’s ISO certificate or company profile and company capability description;

6. Product specifications, circuit diagrams, manuals, block diagrams, operating instructions, etc.;

7. Antenna Peak Gain and Antenna pattern;

8. Test direction (Test direction);

9. The company's business license (the annual inspection cannot expire);

10. Three color photos of EUT (must include each interface and each side);

11. Frequency channel comparison table (only provided if there are many working channels, such as DSSS or FHSS working mode products).

What are the SRRC certification procedures for Bluetooth modules?

1. Submit SRRC certificate application;

2. Application review;

3. If qualified, accept the application and designate a testing institution;

4. The test institution conducts type test;

5. Submit test report;

6. Review the test report;

7. If qualified, SRRC certificate will be issued.

Information required for Bluetooth module SRRC certification

1. The application form for the approval of the radio transmission equipment model requires the signature and seal of the corporate legal person;

2. The power of attorney for the approval of the radio transmission model requires the signature and seal of the corporate legal person;

3. Instruction manual, technical manual, circuit schematic diagram, PCB board diagram, bit number diagram;

4. Description of RF line attenuation and antenna gain description;

5. Drivers and software (if you need to provide computer control, please provide);

6. Equipment photos (6 photos, front and back of the main board, without shielding cover, reflecting the application unit, equipment name, equipment model, equipment serial number, structure size, CMIIT ID;

7. The business license of the enterprise legal person needs to be stamped, and the company's introduction (production capacity, technical strength, quality control) needs to be stamped;

8. The copy of the quality management system certificate is the ISO certificate, and the annual production status table of radio enterprises (not required for Guangdong Province and foreign enterprises).

For SRRC certification, please contact our company ZRLK. We can provide you with professional and efficient testing and certification services with favorable prices and good service. If you provide us with product pictures and specifications, we will give us the corresponding cycle, quotation and specific plan according to your product. Welcome to inquire!
